Home > AUDIO SOURCE > Amplifiers > Octave > Power Amp
> MRE 220
The newly designed MRE 220 mono power amplifier is based on the ultra-reliable MRE 130 and the award winning RE 290 models. The RE 290 was designed for the newly developed KT 120 power tube. This model won the prestigious Golden Sound Award from Hifi Magazine Stereo Sound in Japan and is used as a reference amplifier by many editors. The MRE 220, Octave’s second amplifier designed for the KT 120, achieves a performance that was previously deemed impossible with tube amplifiers with the KT 120 and its new Power Supply and Output-Transformer-Section designs. The output power climbs up to 220 W RMS into 4 Ohms with 300 W Impulse Power. Just to mention a few key specs: The Power bandwidth at full power ranges from 20 Hz up to 70 kHz. The amplifier is stable down to 2.5 Ohm speaker impedance and the S/N ratio is higher than -116dB. The input section can be optionally equipped with a Balanced Input Transformer. Such an Input Transformer eliminates effective ground loops and high frequency noise on the ground line which can affect the sound.
Basic Model : Tube Mono Power Amplifier MRE 220
Tube Complement : 4 x KT120 each Amplifier
Design : Aluminium silver or Aluminium black
Add On Modules : Black-Box and Super Black Box
Power Output : 220 Watt into 4 Ohm
Frequency Response : 5 Hz - 80 kHz / - 3 dB
Total Harmonic Distortion : < 0,1% at 10 Watt into 4 Ohm
Signal-to-Noise Ratio : > 100 dB
Minimum Speaker Impedance : 2 Ohm
Gain/Input Sensitivity : + 29,5 dB
Connections
1 x RCA
1 x XLR Input
Features : ECO Mode, Bias Adjustment, Option Input transformer
General Facts
Power Consumption : 500 Watt at full power
Standard Accessory : Power cord, 3 mm Screwdriverr for BIAS Adjustment, 1 sparetube KT120
Dimensions : W x H x D 488 x 186 x 410
Weight : 29 kg each Amplifier
Formats
CD Formats : Red Book
Audio Formats : WAV, AIFF, FLAC, ALAC, OGG Vorbis, AAC, Windows Media-formatted content files, MP3
Internet Radio Provider : vTuner
Disc Compatability : CD, CD-R, CD-RW
User Control
Front Panel : Touch-sensitive eject and shutdown mode function
TV Monitor : 4:3 and 16:9 customisable TV interface USB touch screen compatible
Web Interface : PC and Mac internet browser compatible Adobe Flash user interface
AMX Creston : Installer-customisable reference apps available
Handheld : User interface app for iPhone and iPod Touch devices
Streaming and Ripping
USB : Scan and play from FAT and NTFS formatted memory sticks
Network Shares : Scan and play from music stored on a network share
Network Storage : Rip to external network storage for expanded music storage
CD Metadata : AllMusic.com online, FreeDB online and local database
StreamNet : 6 user streams to NaimNet and NetStreams systems
Power
Supply Voltage : 100V-230V; 50 or 60Hz
Dimensions (HxWxD) : 87 x 207 x 314 mm
Weight : 4.2 kg
Supplied with : External power supply
Formats
CD Formats Red Book
Disc Compatability CD, CD-R
User Control
Front Panel Seven button matrix
Handheld R-Com
Power
Power Supply Options 555PS, 2 x 555PS
Upgrades
Power Supply 555 PS
Other NAC 252, 552 PS, NAP 500, 500 PS
Dimensions (HxWxD) 114 x 432 x 314 mm
Weight 20.2 kg
Supplied with Hi-Line, R-Com, Burndy x 2, Remote Control NARCOM 4, Clamp 6
